Mark-10 Mesurgauge Load and Travel Analysis Software

item#: MKT020

Mark-10 MESURgauge software expands the functionality of force and torque measuring instruments capturing readings from any force or torque gauge with RS-232 output then displaying the data in tabular and graphical formats. The program includes a set of tools to analyze test results, including statistical calculations, quick data export to Microsoft Excel, customizable reports, pass/fail indicators, and many others. MESURgauge includes a large display screen for real time load and travel data.

Read More...
Choose Options Belowclick on for more info
- required

Serial Cable - Mark-10 Mesurgauge Software

The optional serial cable connects a force gauge to the the computer for data collection.



Back to options

Test Stand Cable - Mark-10 Mesurgauge Software

Use this cable to connect a motorized test stand to the computer to collect data.



Back to options

RSU Adapter - Mark-10 Mesurgauge Software

This adapter converts an RS-232 serial cable to USB.



Back to options

  • Details

Mark-10 MESURgauge is a measuring and analysis program designed to expand the functionality of force and torque measuring instruments. MESURgauge captures readings from any force or torque gauge with RS-232 output and displays data in tabular and graphical formats. Load data can be graphed versus time or distance, particularly useful for such applications as spring testing and tensile testing.

The program includes a set of tools to analyze test results, including statistical calculations, quick data export to Microsoft Excel, customizable reports, pass/fail indicators, and many others. Test setups and sequences are customizable and can be saved and recalled. The user can program test start and stop conditions, including load, time, distance, and sample break.

Additional features in MESURgauge include a large display screen for real time load and travel data and a utility to configure Mark-10 gauges from a PC. Built-in simulated data generation allows MESURgauge to be evaluated without a gauge.

Features -
Mark-10 Mesurgauge Software

  • Inputs data from a force or torque gauge and travel display to a PC for further analysis
  • Real time tabular and graphical data displaying load vs. time or load vs. distance
  • Configurable start and stop test triggers (time, load, number of samples, or distance)
  • Statistical calculations (minimum, maximum, average, area under curve) for a user-selectable data range
  • Graph manipulation tools, including zooming, scaling, panning, titles, and more
  • One-button export to Excel
  • Create customizable reports and report templates
  • Compatible with all Mark-10 and other force and torque measuring instruments
  • Save and recall test setups and test data
  • Configure Mark-10 instruments easily through a simple interface
  • View real time data on a large simulated instrument display

View real time data in graphical and tabular formats

Sophisticated analysis tools include an x-y cursor, statistics, and more

View real time load and travel readings on an enlarged simulated instrument display

Configure test start and stop conditions

High and low limit indicators help differentiate between an acceptable sample and a reject

Easily customize reports and report templates

Reports can be saved to an HTML file or sent directly to a printer

Mark-10 gauge settings can be configured through a simple interface

Computer requirements:

  • Windows 2000 or later operating system
  • At least 150 MB of free hard disk space
  • Minimum screen resolution of 1024 x 768

Customer Reviews

Mark-10 Mesurgauge Load and Travel Analysis Software
$470.25
