Shimpo FGS-250W Hand Wheel Operated Test Stand, 250 lb (125 kg), Vertical or Horizontal

SMP084 |

| Click Here to Learn How to Use This Builder

Selected But Not Shown

      The FGS-250W Hand Wheel Operated Test Stand's movement is created from a trapezoidal screw drive with integral nut. Combined with its top-mounted wheel that effortlessly and smoothly turns, stable resolution is easily achieved during operation. The unit offers dual functionality and can be used in either the vertical or horizontal positions with no extra equipment. Simply lay the unit on its back and level with the adjustment screw to run horizontal tests.

      The FGS-250W's compact design and minimal footprint enables movement and usage in a myriad of locations and testing situations.


      • Flexible Vertical or Horizontal operation
      • Compact footprint and lightweight construction enables usage in almost all locations
      • Fine movement from the top-mounted wheel aids in precision testing
      • 250 lb (125 kg) maximum testing capacity
      • Digital Scale kit available for high resolution movement recording
      • Optional Tensile Frame Kit extends movement stroke to over 10 inches


      Dimensions 9.8" W x 7.7" D x 17.5" H
      Weight 15.4 lb
      Capacity Up to 250 lb (125 kg)
      Travel 0.12" (3 mm)/turn
      Stroke 9" (230 mm) max
